PCB Component Sourcing
Immaculate Component Sourcing Made Simple
Getting the right components for your PCB is the first step towards engineering the product functionalities you seek. Even a small mishap in the process can lead to capital losses, functional asymmetries in the expected & real performance, as well as operational hazards caused by the delay and change orders.
While every enterprise and individual working with PCB understands the risks of inaccurate component sourcing, having a systematic process that assures high accuracy throughout the component sourcing cycle takes extensive expertise, experience, and a network of distributors. We bring all the necessary resources you will need to source the precise components you seek for your PCB manufacturing or assembly operation.
Over years of optimization, we have created a platform that works like a symmetrical engine – the more concise, complete, and consistent your Bills of Materials are, the more accurately we can source components for you. We have developed a proprietary network of distributors across the globe that provide:
- Precision in terms of functionalities and features you seek from your PCB components
- Adherence to industry-accepted standards of manufacturing
- Provide optimal lead-time
- Value creation at the behest of delivery exactly what you need, within the budget you need
We help you focus on your core operations by deploying our expertise across the sourcing process. From interfacing with distributors to procuring the components, even if you do not possess a dedicated purchase team, we ensure your received quality of components matches your budget and requirements seamlessly.
Sourcing Efficiency Delivered with Every Component
- No Minimum Order Quantity
- Dedicated Sourcing Team
- Tens of Thousands of Components in Stock
- Experience-Driven Advisory Across the PCB Sourcing Cycle
- Transparency and Traceability of Components
- Price Efficiency Attained with the Help of a Global Sourcing Network
- Industry-Leading Quality of Components Available at Value-Delivering Prices
Here is the standard Bills of Materials that can help us generate value for you in the Component Sourcing process:
| Quantity | Reference | Value | Part Type | PCB Footprint | Manufacturer Part No | Manfacturer Name | |
|---|---|---|---|---|---|---|---|
| 1 | C1 | 0.1µF /275VAC | CAP Polypropline | th_10x0_7mm_c1 | R46KF310040P0M | KEMET | 0.1µF Film Capacitor 275V 560V Polypropylene (PP), Metallized Radial 0.512" L x 0.236" W (13.00mm x 6.00mm) |
| 2 | C2,C3 | 4.7uF/400V | CAP | th_10x12_5mm_c2 | UVC2G4R7MPD1TD | NICHICON | 4.7uF/400V TH electrolytic capacitoracitor, D”]L=8.0x13mm, 3.0mm lead spacing, 20%, vertically placed |
| 1 | C4 | 1000pF/1KV | CAP | c1206_c4 | GRM31BR73A102KW01 | MURATA ELECTRONICS | 1000pF 1000V (1kV) Ceramic Capacitor X7R 1206 (3216 Metric) 0.126" L x 0.063" W (3.20mm x 1.60mm) |
| 3 | C6,C9,C15 | 0.1uF/50V | CAP | c0402_c5 | GRM155R71H104KE14J | MURATA ELECTRONICS | 0.1µF 50V Ceramic Capacitor X7R 0402 (1005 Metric) 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| 1 | C5 | 100uF/25V | CAP | th_11x6_3mm_c6 | UHE1E101MED | NICHICON | THM electrolytic cap,100uF,25V,20%,RADIAL,Case size DxL=6.3mmx11mm, 2.5mm lead space |
